WHEN YOU NEED A CUT ABOVE

This is the pro-choice for contour-cutting of brush and grass that you can depend on. The Mahindra F-Series flex-wing rotary cutters are ideal for airports, campuses, estates, farms, parks, orchards, and roadsides. But that’s not all. The Flex-Wing deck design lets you cut on rolling terrain without having to make multiple passes and are available in three widths, including 10, 12, and 15 feet.

With a more compact design than our F-10 model, The F-12 Flex Wing rotary cutter makes narrow turns and close cuts around trees, thanks to its pivoting hitch and form-fitting tires. And it's unique wing-bar blade keeps it lightweight while protecting the gearbox output shaft.

Request More Information

By pressing SUBMIT, you agree that DX1, LLC and Central Coast Yamaha Polaris Suzuki Can-Am may call/text you at the number provided, for either informational or marketing purposes, using an automatic telephone dialing system or pre-recorded/artificial voices. Msg/data rates may apply. You don’t need to consent as a condition of any purchase & you may revoke your consent at any time. You also agree to our Privacy Statement & Terms of Use.

Mahindra F-12

Condition
New
Category
Cutter Implements
Model Type
Flex Wing Rotary Cutters
Model Code
RCRHD12SCFLL
Color
Red

Features

  • Jack stand - Standard
  • Gearbox oil (85W-140) - Factory-filled Lucas oil
  • Wing lift - Hydraulics
  • Safety tow chain - Standard
  • LED light kit - Standard
  • Safety - Chain guards

Features & Benefits

  • Safety features include deflectors and / or chain guards to protect people, passing cars, and buildings from rocks and debris.
  • Replaceable, anti-scalping skid shoes for excellent ground contouring and long-lasting deck life.
  • Heavy-duty turn buckles for fewer breakdowns and less stress.
  • Smooth, thick wall decks for easy cleanup, preventing rust, and long life.
  • Easy-lift composite hood for quick maintenance.
  • 5-year limited gearbox warranty for peace-of-mind.
  • Works with PTOs discharging 35 – 60 hp.
  • Transport width fits through a 9-ft gate.
  • 12-ft wide cutting deck.
  • Bi-directional pivoting hitch for impressive short turning radius in tight spaces.
  • 2- to 12-inch cutting height.
  • 1.5-inch diameter cutting capacity.

General Information

Manufacturer
Mahindra
Model
F-12
Model Code
RCRHD12SCFLL
Color
Red

Dimensions

Cutting Height Range
2 - 12 in. (cutting height dependent on tire size)
Weight
Approximate - 2,750 lb.
Height

Transport - 65 in.

Adjustment - Hydraulic cylinder

Width

Overall - 155 in.

Transport - 97 in.

Cutting Width
144 in.
Length
Overall - 148 in.

Measurements

Deck Thickness

Center - 12 ga. top / 10 ga. bottom

Wing - 12 ga. top / bottom

Blade Size
1/2 x 3 in. high lift
Skirt Thickness
Side - 1/4 x 11-1/2 in.
Blade Overlap
6 in.
Blade Tip Speed

Center 540 rpm - 14,504 fpm

Wing 540 rpm - 13,925 fpm

Bladeholder/Carrier
Carrier - Infinity steel
Wing Flex Range

Up - 88°

Down - 25°

Cutting Capacity
Diameter - 1-1/2 in.

Operational

Hitch
Pull-type - Pull-swivel
Wheels
Foam-filled
Driveline Protection
Slip clutch
Tires
Foam-filled
Driveline -- Wing
ASABE - CAT 3
Cutter Type
Rotary
Horsepower
Tractor PTO range - 35 - 60 hp
Output Shaft
Diameter - 1-9/16 in.
Transport Tongue Weight
748 lb.
Driveline -- Center
ASABE - CAT 4 equal angle
Tractor Size

Compatible with 2660, 2670, 6065 / 6075

For older Mahindra tractor models that are not listed on the compatibility sheet, please consult with your Mahindra dealer for your implement selection.

Gearbox HP Rating

Power divider - 160 hp

Center & Wing - 65 hp

Gearbox ratings based on field performance

Other

Warranty

1 year full

Gearbox - 5-year limited (For non-commercial use only)
